HXT 300/500V/XLPE / OS / LSZH低烟无卤仪表电缆：FR-XOL、CU/MGT/XLPE/OS/LSZH、双绞线和三绞线、云母带、XLPE绝缘、整体铝箔屏蔽、LSZH护套电缆、300/500V、BS EN50288-7

HXT 300 / 500V / XLPE / OS / LSZH low smoke halogen-free cable: fr-xol, Cu / Mgt / XLPE / OS / LSZH, twisted pair and twisted pair, mica tape, XLPE insulation, overall aluminum foil shielding, LSZH sheathed cable, 300 / 500V, BS en50288-7

• 导体

  细裸铜丝绞合导体

• 防火层

  云母带

• 绝缘

  交联聚乙烯绝缘料

• 芯线结构

  芯线两两成对绞合

• 屏蔽

  铝塑复合薄膜静态屏蔽，带镀锡排流线

• 外护套

  低烟无卤护套料

• 外护套颜色

  橙色

Structure

• Conductor

  Stranded fine bare copper wire conductors

• Insulation

  XLPE insulating material

• Fire Barrier:

  Mica Tape (MGT)

• Core structure

  Wires twisted in pairs

• Shield

  Aluminum plastic composite film static shielding with tinned drain wire

• Sheath

  LSZH sheath

• Outer sheath colour

  Orange


• 额定电压

  300/500V

• 工作温度

  -40°C 至 +125°C

• 阻燃标准

  IEC60332-3-22，BS EN60332-3-22

• 特性

  EN 61034-1+2 / IEC 61034-1+2

  IEC 60754-2

  环保符合RoHS指令

  阻燃性符合IEC60332-3-22，BS EN60332-3-22

  铝塑复合薄膜静态屏蔽，带镀锡丝排流线，使高频电磁干扰最小化

  对绞结构可使电路去耦（串音效果）

• Technical Parameters

• Rated voltage

  300/500V

• Working temperature

  - 40 ° C to + 125 ° C

• Flame retardant standard

  IEC60332-3-22，BS EN60332-3-22

• Characteristic

  EN 61034-1+2 / IEC 61034-1+2

  IEC 60754-2

  Environmental protection complies with ROHS directive

  Flame retardancy conforms to IEC60332-3-22，BS EN60332-3-22

  Aluminum plastic composite film static shielding with tinned wire drainage line to minimize high-frequency electromagnetic interference

  Twisted pair (TP) structure can decouple the circuit (crosstalk effect)
